Slide Rail Rack Mount Fiber Patch Panel
2
3
4
5

Slide Rail Rack Mount Fiber Patch Panel

Name: China Slide Rail Rack Mount Fiber Patch Panel Manufacturers Suppliers Factory - Good Price
Brand: Babaolu
SKU: 221002042

Introduction Our Slide Rail Rack Mount Fiber Patch Panel offers convenient cable connections between external plants and equipment in buildings and communication facilities. It combines fiber fusion, storage, and cable connection functionalities into one compact unit. This versatile panel...

Send Inquiry

Description

Technical Parameters

Introduction

Our Slide Rail Rack Mount Fiber Patch Panel offers convenient cable connections between external plants and equipment in buildings and communication facilities. It combines fiber fusion, storage, and cable connection functionalities into one compact unit. This versatile panel supports both bundle type and ribbon type fiber optic cables. With ample space for integrated pigtails, cables, and adapters, it efficiently manages fiber resources. Additionally, its standard 19" design and removable adapter plates on the sturdy metal front cover enhance flexibility. Getting started with our product is a breeze, saving you valuable time and effort. If you have any interest in our offerings, please feel free to reach out and engage in a conversation with us.

Feature

Our Slide Rail Rack Mount Fiber Patch Panel is designed to maintain an organized fiber optic cable system. It boasts a versatile entrance port that can accommodate single fiber, bundle and ribbon fiber optic cables. This rack mount is ideal for indoor use, equipped with plastic parts that are made to withstand corrosion and metal parts that are electrostatically treated to increase their resistance to corrosion even further. Moreover, we offer a pull-out design and an integrated fusion wiring module for easy, hassle-free fusion wiring. You can trust our product to provide excellent performance and durability in any setting.

Specification:

Fiber Capacity of panel	12-144 core(12 24 48 port usually)
Panel Connector	SC LC ST FC
Dimension	19'' 1U/2U/3U/4U...
Material	Cold Rolled Steel or Aluminum
Storage Temperature	-45~+75℃
Thickness	1.0 1.2 mm

More information about Us:

Conpany Offer	Our Service	FAQ
QUAIITY IS OUR CULTURE	24*7 after sales service,reply within 2 hours	Is a good price with high quality ? Yes, Competitive advantage price with Good quality
WITH US YOUR MONEY IN SAFE YOUR BUSINESS IN SAFE	Quality with CQC certificate	Warranty : Full refund in case of bad quality or late delivery and Offer 3 years warranty
WE ARE YOUR NEXT GENERATION NETWORKS PARTNER	Free sample of offer &Small order welcome	Payment Method Paypal/T/T/Western Union/Trade Assurance/Credit card /Western Union
	Confidentiality agreement "Business secret contract"	Quality assurance Contract

Production Inforamtion

Standard Operating Wavelength	850nm,1310nm ,1550nm
Insertion loss	≤0.3dB, additional loss variation is not more than 0.2dB, additional loss variation of not more than 5dB
Return loss	PC≥40dB,UPC≥50dB,APC≥60dB
Dielectric strength	≥ 3KV (DC) / 1min without breakdown, no arcing
Insulation resistance	≥ 1000MΩ / 500V (DC) Life: ≥ 1000 times
Optical fiber bending radius	≥40mm
Optical fiber connector	500 times after plugging: no mechanical damage, the pin surface without obvious scratches
