Pigtail Sc APC
Description
Technical Parameters
Description
The Pigtail Sc APC is an optical fiber type that comes with an optical connector pre-installed on one end and an exposed optical fiber on the other. This allows for a convenient connection with other optical fibers, such as those found in distribution frames or equipment. Manufactured according to industry standards, it ensures stable signal transmission and durability. Additionally, it simplifies fiber termination, saving valuable time and reducing labor costs.
Features
Our Pigtail Sc APC utilizes a top-notch pigtail cable to deliver exceptional performance for optical cable terminals. By incorporating the right fusion joint, it ensures optimal functionality and longevity, eliminating the need for frequent replacements. This product finds extensive usage in optical fiber management equipment such as ODF, optical fiber terminal box, and distribution box, providing convenience and ease of operation.
Parameter
Item | SM(Single Mode) | MM(Multimode) | |||
Fiber Cable Type | G652D/G655/G657A1/G657A2 | OM1 | OM2/OM3/OM4 | ||
Fiber Diameter (um) | 9/125 | 62.5/125 | 50/125 | ||
Cable OD (mm) | 0.9/1.6/1.8/2.0/2.4/3.0 | ||||
Endface Type | PC | UPC | APC | UPC | UPC |
Typical Insertion Loss (dB) | <0.2 | <0.15 | <0.2 | <0.1 | <0.1 |
Return Loss (dB) | >45 | >50 | >60 | / | |
Insert-pull Test (dB) | <0.2 | <0.3 | <0.15 | ||
Interchangeability (dB) | <0.1 | <0.15 | <0.1 | ||
Anti-tensile Force (N) | >70 | ||||
Temperature Range (℃) | -40~+80 | ||||




Application
1. SC, LC, FC, MU, ST, MT-RJ, E2000 connector available;
2. Superior qualified standard PC, APC, UPC, SPC polishing
3. φ0.9mm, φ2.0mm, φ3.0mm cable optional;

QA&QC

Storage,Handling and Transportation

Strategic partner with Babaolu
3,800 customers from more than 70 countries in the past 10 years.
