Pigtail Sc Upc

Description The Pigtail Sc Upc is an excellent choice when it comes to manufacturing communication equipment in the field for splicing optical fiber. This product guarantees to meet all your mechanical and performance requirements with its top-notch quality. It adheres to industrial standards...
Send Inquiry

Description

Technical Parameters

Description

The Pigtail Sc Upc is an excellent choice when it comes to manufacturing communication equipment in the field for splicing optical fiber. This product guarantees to meet all your mechanical and performance requirements with its top-notch quality. It adheres to industrial standards and is designed, manufactured, and tested based on established protocols and performance standards. One end of the Pigtail Sc Upc comes pre-installed with an optical fiber connector, while the other end is equipped with an exposed optical fiber section that can connect to any distribution frame or equipment. You can trust this product to perform efficiently and effectively in any setting.


Features

Our Pigtail Sc Upc boasts a removable protective outer sheath, making it an ideal solution for installations with strict bending radius requirements or high-density environments. With this feature, there's no need to go through the trouble of field terminations. Furthermore, it is crafted with durable materials that ensure a long service life and excellent resistance against rain-induced corrosion, making it a suitable choice for outdoor use.
By incorporating our Pigtail Sc Upc, efficiency can be significantly improved, saving valuable time. Moreover, it guarantees low back reflection and insertion loss, resulting in reliable performance. This makes it a perfect fit for data centers, local installations, and data processing networks. Experience the convenience and reliability our product brings to your connectivity needs.




Item

SM(Single Mode)

MM(Multimode)

Fiber Cable Type

G652D/G655/G657A1/G657A2

OM1

OM2/OM3/OM4

Fiber Diameter (um)

9/125

62.5/125

50/125

Cable OD (mm)

0.9/1.6/1.8/2.0/2.4/3.0

Endface Type

PC

UPC

APC

UPC

UPC

Typical Insertion Loss (dB)

<0.2

<0.15

<0.2

<0.1

<0.1

Return Loss (dB)

>45

>50

>60

/

Insert-pull Test (dB)

<0.2

<0.3

<0.15

Interchangeability (dB)

<0.1

<0.15

<0.1

Anti-tensile Force (N)

>70

Temperature Range (℃)

-40~+80




QA&QC

BL-17_02

Storage,Handling and Transportation

BL-19_07
