Otdr Nk4000

Name: China Otdr Nk4000 Manufacturers Suppliers Factory - Good Price Otdr Nk4000 - BABAOLU
Brand: Babaolu
SKU: 221002052

Description The Otdr Nk4000 is an intelligent measuring device created for testing optical fiber communication systems. With its 5.8 inch color touch screen, it enables users to operate through buttons or a touch interface, making issuing operation instructions a breeze. The instrument...

Send Inquiry

Description

Technical Parameters

Description

The Otdr Nk4000 is an intelligent measuring device created for testing optical fiber communication systems. With its 5.8 inch color touch screen, it enables users to operate through buttons or a touch interface, making issuing operation instructions a breeze. The instrument incorporates eight functional modules that can help in addressing various on-site testing and maintenance requirements while ensuring precise and accurate results. The user-friendly design of this portable device provides a fantastic user experience, enabling users to perform tests with ease.

Features

The Nk4000 OTDR boasts an outstanding dynamic range of 45dB, along with a penetrable splitter that makes PON network testing a breeze, detecting issues with ease. With its impeccable sensitivity, any fiber link element's detection, location, and measurement become effortless, making optical fiber maintenance more straightforward than ever. The device is incredibly energy efficient, using intelligent power-saving management to ensure continuous testing while minimizing power loss. The Nk4000 OTDR is the perfect tool for all your optical fiber testing needs.

Product Specification

Product	The Multi-Function Optical Time Domain Reflectometer, known as the NK5600 Series, is a versatile device designed for various applications. Its primary function is to measure the characteristics of optical fibers by sending light pulses and analyzing the reflections. With advanced technology and features, the NK5600 Series offers accurate and reliable results. Whether used in telecommunications, network maintenance, or fiber optic installation, this device proves to be a valuable tool. Its multi-functionality ensures maximum efficiency and effectiveness. Discover the capabilities of the NK5600 Series and experience its exceptional performance in the field.
Model	A	B	C	D	E	F		G	H	I
Fiber type	SM								MM	SM&MM
Wavelength(nm)	1310/1550				1310/1490/1550	1310/1550/1625		1310/1550/1625	850/ 1300	850/1300/1310/1550
Maximum dynamic range(dB)	35/33	38/36	42/40	45/43	37/35/35	32/30/28		37/35/35	26/28	26/28/37/35
Event dead zone(m)	1	0.8	0.8	0.8	0.8	0.8		0.8	1	1
Attenuation dead zone(m)	6	6	6	6	6	6		6	6	6
Display	5.8 inch color LCD with touch screen						size: 227 mm 160 mm 70mm
Measuring range	500m /l km /2 km /4 km /8 km /16 km /32 km /64 km /128 km /256km
Measuring pulse width	5ns/ 10ns/ 5Ons/ 160ns/ 320ns/ 500ns/1000ns/ 5000ns/ 1000ns/ 2000ns
Ranging accuracy	± (0.75m+ Sampling interval +0.005% x Test distance)
Loss precision	± 0.05dB
Reflection accuracy	± 3dB
Data storage	≥2000
Interface type	FC/ PC (Replaceable SC, ST)
Communication interface	USB, mini-USB, 10M/100M Ethernet
VFL output	≥5mW

Application

It is mainly used to measure the length, loss and connection quality of all kinds of optical fibers and cables, and can be widely used in engineering construction, line maintenance and testing, emergency repair, and the development and production of optical fibers and cables.
